Chassis:
Fully updated spaceframe using mainly 38mm x 1.5mm dia tube
Market leading torsional rigidity
Fully welded roll cage in 45mm CDS with welded rear braces
Powder coated in satin black
Panelled in 1.5mm NS4 alloy sheet
Wing:
Double element track design in carbon fibre, designed with excellent rearward visibility
Body:
Unpainted GRP finished in immaculate gel coat finish utilising the latest advances in pigment technology
Carbon fibre Ultima Evolution wing mirrors option
Carbon fibre Ultima Evolution front splitter option
Ultima Evolution badges
Rear view camera and parking sensors option
Interior:
Ultima Evolution branded leather/alcantara seats and dashboard
Ultima Evolution branded instruments colour coded option
Carpet for the floor and rear bulkhead with colour coded piping option
Leather trimmed roll cage option
Air Conditioning
Stainless steel handbrake lever
Ultima Evolution branded luggage bag set
Steering wheel mounted wireless switch gear
Alpine in car entertainment system with sat nav option
Lighting:
Full LED lighting front and rear to Ultima Evolution design with a carbon fibre style headlight cluster arrangement and machined aluminium anodised bezels. LED side indicator repeaters
Screen:
Laminated glass. Full U.S.A. and European certified
Heated windscreen option
Suspension:
TIG welded double unequal length wishbones with extended length front wishbones
Alloy uprights in LM25
Fully adjustable custom made coil spring dampers for bump, rebound and ride height
Steering:
Alloy sports Ultima EVO quick ratio steering rack 2.1 turns lock to lock
Brakes:
12.7" curved vane vented disc brakes all round
Adjustable brake bias front to rear. All s/s TUV hoses
Engine:
Chevrolet V8 LS fuel injection from 350bhp to 1020bhp
Gearbox:
Porsche six speed manual transaxle with machined billet quick shifter cable change system
Wheels:
Forged Lightweight and Flow Formed alloy one piece Ultima Evolution wheels with Ultima Evolution centre caps
Tyres:
Michelin 18" and 19" options
Performance (1020bhp 6800cc SUPERCHARGED LS V8 ULTIMA EVOLUTION):
0-60mph: 2.3 secs
0-100mph: 4.9 secs
30-70mph: 1.5 secs
0-150mph: 8.9 secs
0-100-0 mph: 8.8 secs
Standing quarter mile: 9.2 secs @ 156mph
Top speed: 240+ mph (gearing limited)
Performance (700bhp 7000cc LS7 V8 ULTIMA EVOLUTION):
0-60mph: 2.6 secs
0-100mph: 5.3 secs
30-70mph: 1.8 secs
0-150mph: 10.4 secs
0-100-0 mph: 9.4 secs (World Record)
Standing quarter mile: 9.9 secs @ 143mph
Top speed: 200+ mph (gearing limited)
Top Gear Track: 1min12.8 secs (road tyres) 1min 9.9 secs (slicks)
Performance (480bhp 6200cc LS3 V8 ULTIMA EVOLUTION):
0-60mph: 3.1 secs
0-100mph: 6.4 secs
30-70mph: 2.4 secs
0-150mph: 13.2 secs
0-100-0 mph: 10.5 secs
Standing quarter mile: 11.4 secs @ 129mph
Top speed: 180+ mph (gearing limited)
Top Gear Track: 1min 15.9 secs
Dimensions:
Length: 4000mm
Width: 1850mm
Height: 1070mm
Wheelbase: 2560mm
Ground Clearance: 120mm (adjustable)
Weight: 950kg
